# cat /etc/dhcp/dhcpd.conf

#
# DHCP Server Configuration file.
#   see /usr/share/doc/dhcp*/dhcpd.conf.example
#   see dhcpd.conf(5) man page
#
option client-system-arch code 93 = unsigned integer 16;

allow booting;
allow bootp;

ddns-update-style none;

subnet 192.168.10.0 netmask 255.255.255.0 {
        range 192.168.10.100 192.168.10.200;
        option subnet-mask 255.255.255.0;
        default-lease-time 21600;
        max-lease-time 43200;
        class "pxeclients" {
		match if substring (option vendor-class-identifier, 0, 9) = "PXEClient";
	        next-server 192.168.10.1;
		if option client-system-arch = 00:07 or option client-system-arch = 00:09 {
       			filename "BOOTX64.efi";
		} else {
       			filename "pxelinux.0";
		}
	}
}

# cat /etc/xinetd.d/tftp

# default: off
# description: The tftp server serves files using the trivial file transfer \
#	protocol.  The tftp protocol is often used to boot diskless \
#	workstations, download configuration files to network-aware printers, \
#	and to start the installation process for some operating systems.
service tftp
{
	socket_type		= dgram
	protocol		= udp
	wait			= yes
	user			= root
	server			= /usr/sbin/in.tftpd
	server_args		= -s /tftpboot
	disable			= no
	per_source		= 11
	cps			= 100 2
	flags			= IPv4
}

# vi /tftpboot/pxelinux.cfg/default


default linux
# default vesamenu.c32
timeout 600

display boot.msg

# Clear the screen when exiting the menu, instead of leaving the menu displayed.
# For vesamenu, this means the graphical background is still displayed without
# the menu itself for as long as the screen remains in graphics mode.
menu clear
menu background splash.png
menu title CentOS 7
menu vshift 8
menu rows 18
menu margin 8
#menu hidden
menu helpmsgrow 15
menu tabmsgrow 13

# Border Area
menu color border * #00000000 #00000000 none

# Selected item
menu color sel 0 #ffffffff #00000000 none

# Title bar
menu color title 0 #ff7ba3d0 #00000000 none

# Press [Tab] message
menu color tabmsg 0 #ff3a6496 #00000000 none

# Unselected menu item
menu color unsel 0 #84b8ffff #00000000 none

# Selected hotkey
menu color hotsel 0 #84b8ffff #00000000 none

# Unselected hotkey
menu color hotkey 0 #ffffffff #00000000 none

# Help text
menu color help 0 #ffffffff #00000000 none

# A scrollbar of some type? Not sure.
menu color scrollbar 0 #ffffffff #ff355594 none

# Timeout msg
menu color timeout 0 #ffffffff #00000000 none
menu color timeout_msg 0 #ffffffff #00000000 none

# Command prompt text
menu color cmdmark 0 #84b8ffff #00000000 none
menu color cmdline 0 #ffffffff #00000000 none

# Do not display the actual menu unless the user presses a key. All that is displayed is a timeout message.

menu tabmsg Press Tab for full configuration options on menu items.

menu separator # insert an empty line
menu separator # insert an empty line

label linux
  menu label ^Install CentOS 7
  kernel vmlinuz
  append initrd=initrd.img ip=dhcp inst.stage2=ftp://192.168.10.1 ks=ftp://192.168.10.1/pub/ks.cfg quiet
  # append initrd=initrd.img inst.stage2=hd:LABEL=CentOS\x207\x20x86_64 quiet

label check
  menu label Test this ^media & install CentOS 7
  menu default
  kernel vmlinuz
  append initrd=initrd.img inst.stage2=hd:LABEL=CentOS\x207\x20x86_64 rd.live.check quiet

menu separator # insert an empty line

# utilities submenu
menu begin ^Troubleshooting
  menu title Troubleshooting

label vesa
  menu indent count 5
  menu label Install CentOS 7 in ^basic graphics mode
  text help
	Try this option out if you're having trouble installing
	CentOS 7.
  endtext
  kernel vmlinuz
  append initrd=initrd.img inst.stage2=hd:LABEL=CentOS\x207\x20x86_64 xdriver=vesa nomodeset quiet

label rescue
  menu indent count 5
  menu label ^Rescue a CentOS system
  text help
	If the system will not boot, this lets you access files
	and edit config files to try to get it booting again.
  endtext
  kernel vmlinuz
  append initrd=initrd.img inst.stage2=hd:LABEL=CentOS\x207\x20x86_64 rescue quiet

label memtest
  menu label Run a ^memory test
  text help
	If your system is having issues, a problem with your
	system's memory may be the cause. Use this utility to
	see if the memory is working correctly.
  endtext
  kernel memtest

menu separator # insert an empty line

label local
  menu label Boot from ^local drive
  localboot 0xffff

menu separator # insert an empty line
menu separator # insert an empty line

label returntomain
  menu label Return to ^main menu
  menu exit

menu end

# /var/ftp/pub/ks.cfg

#platform=x86, AMD64, 或 Intel EM64T
#version=DEVEL
# Install OS instead of upgrade
install
# X Window System configuration information
xconfig  --startxonboot
# Keyboard layouts
# old format: keyboard us
# new format:
keyboard --vckeymap=cn --xlayouts='cn'
# Root password
# password: 123456
# rootpw --iscrypted $1$tczqctJg$tQbT39eH4XwhvmKwh9tLz/
rootpw --iscrypted $1$zY8JPQGF$/0SuPWCYhf3QbRQRe/nv90
# System language
lang zh_CN.UTF-8
# user --groups=wheel --name=hileveps --password=$6$NeWwSpeU8PkXgi7r$j8JHJbaBMIdmBwO4cg0P.NLPeqg3K7qvwqXVZKP3Eb8dFeGygDubn1U/7C2JvxLqLoWcb//NDi.GqPEDVMvXC/ --iscrypted --gecos="hileveps"
user --groups=wheel --name=hileveps --password=$6$dGXjqr9RxmqEstqx$S9DYIuHLZaK3pEXYLyNINrj9FS62B2FW83iEOpWDvc3WioZ8jQeUlc.Q1BWjDdeh6cxQqrMQg2ElCKMgXqStw0 --iscrypted --gecos="hileveps"
# System authorization information
auth  --useshadow  --passalgo=sha512
# Use CDROM installation media
# cdrom
url --url=ftp://192.168.10.1
# Use graphical install
graphical
# Run the Setup Agent on first boot
firstboot --enable
# SELinux configuration
selinux --enforcing

# repo
# repo --name=hileveps_repo --baseurl=ftp://192.168.10.1/hileveps_repo
repo --name=epel  --baseurl=ftp://192.168.10.1/hileveps_epel/epel

# System services
services --enabled="chronyd"
ignoredisk --only-use=sda
# Firewall configuration
firewall --disabled
# Network information
network  --bootproto=dhcp --device=enp2s0
network  --bootproto=dhcp --device=None
# Halt after installation
halt
# System timezone
timezone Asia/Shanghai
# System bootloader configuration
bootloader --append=" crashkernel=auto" --location=mbr --boot-drive=sda
autopart --type=lvm
# Partition clearing information
# @^minimal
clearpart --all --initlabel --drives=sda

%packages
@X Window System
@Xfce
@core
chrony
kexec-tools
wqy-zenhei-fonts


%end
